Headlight Assembly for 2002 2003 2004 Acura RSX Headlamp Replacement, Chrome Housing Amber Reflector

SPECIFICATION AND FITMENT

Product Description:

• High Beam: H1(Not included)
• Low Beam: H1(Not included)
• Color: Chrome Housing +Clear lens + Amber Reflector
• Replace Parts Number:7221-0031
• Replace Partslink:AC2518101,AC2519101
• OE Number:33151-S6M-A01,33101-S6M-A01

Fitment:

• 2002 2003 2004 Acura RSX Base Coupe 2-Door 2.0L
• 2002 2003 2004 Acura RSX Type-S Coupe 2-Door 2.0L

Package includes:

2 x Headlights(1x Driver's side & 1x passenger's sides),bulbs are not included

How to Adjust Your Headlights

Note:
Before you begin to adjust the light, make sure to check the alignment of your lights first. Park the vehicle about 10 to 25 feet from the wall with the lights aimed at the wall. The centerlines of the headlights should not be any higher than 3.5 feet above the ground.​

1. Find the adjustment screws. Firstly, locate the adjustment screws on your vehicle.
2. Adjust the headlights individually. The headlights should be adjusted one at a time. Put a rag or towel over a chair in front of the light you want to block. Covering the light assembly directly can damage the plastic lens.
3. Adjust the vertical field. The screw on the top of the light housing should be turned clockwise to raise the lights and counterclockwise will lower the light. The headlight should be adjusted until the top of the most intense part of the light beam shines directly on or just below the center of the tape line on the wall.
4. Adjust the horizontal field. The screw on the side of the light housing should be turned to get the right/left adjustment correct. Adjust the lens so that the most intense part of the beam is to the right of the vertical line.
5. Test your results.
